Flanged Head Bolt-Sh M6X12
SP0906041
Enquiry ↗CATALOGUE DRAWING
This part is reference 23
Jawa 42 Bobber · Rev 17 · p. 117Original parts list ↗
Highlighted catalogue reference 23. The image shows the complete assembly.
Bolt Flange 6X10 · 95701-06010-08
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Side Panel LH & RH Assy / ECU & Relay / Fusebox / Lock Set Kit. Match reference 23 in the drawing. Assembly quantity: 2. Choose the quantity you need in your enquiry above.
Bolt Flange 6X10 specifications & catalogue names
- Part number
- 95701-06010-08
- Catalogue part name
- BOLT FLANGE 6X10
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberBolt Flange 6X10Rev 17 · PDF p. 130 | Side Panel LH & RH Assy / ECU & Relay / Fusebox / Lock Set KitRef 23 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 BobberBolt Flange 6X10Rev 17 · PDF p. 150 | Electrical Components Mounting On Frame & Handle BarRef 9 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 FJBolt Flange 6X10Rev 09 · PDF p. 68 | Fuel Tank AssemblyRef 5 · Assembly qty. 6 | Confirm exact bike variant. |
| Jawa PerakBolt Flange 6X10Rev 24 · PDF p. 134 | Side Panel LH & RH Assy / ECU & Relay / FuseboxRef 23 · Assembly qty. 2 | Confirm exact bike variant. |
