Jawa & Jawa 42 Platform · Rev 36 · p. 53Original parts list ↗
Highlighted catalogue reference 24. The image shows the complete assembly.
Flange Head Bolt Sh M6X28 · Sf0102034
Listed in the supplied Jawa & Jawa 42 Platform catalogue, revision 36, under Magneto Cover LH - BSIV & BSVI. Match reference 24 in the drawing. Assembly quantity: 2. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Flange Head Bolt Sh M6X28 (Chrome)
Flange Head Bolt Sh M6X28 specifications & catalogue names
- Part number
- Sf0102034
- Catalogue part name
- FLANGE HEAD BOLT SH M6X28 / FLANGE HEAD BOLT SH M6X28 (CHROME)
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa & Jawa 42 PlatformFlange Head Bolt Sh M6X28Rev 36 · PDF p. 69 | Magneto Cover LH - BSIV & BSVIRef 24 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIFlange Head Bolt Sh M6X28 (Chrome)Rev 06 · PDF p. 46 | Magneto Cover LHRef 20.1 · Assembly qty. 3 | RED WOLF |
