Nut Hx Nyl Fl M10X1.50X13.5X10
SF0315017
Enquiry ↗CATALOGUE DRAWING
This part is reference 5
Jawa Perak · Rev 24 · p. 129Original parts list ↗
Highlighted catalogue reference 5. The image shows the complete assembly.
Upper Bracket · T05000KW0080N
Listed in the supplied Jawa Perak catalogue, revision 24, under Handle Bar Assembly. Match reference 5 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Upper Bracket Jawa 42 Dual Disc
Upper Bracket specifications & catalogue names
- Part number
- T05000KW0080N
- Catalogue part name
- UPPER BRACKET / UPPER BRACKET_JAWA 42 DUAL DISC
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa PerakUpper BracketRev 24 · PDF p. 142 | Handle Bar AssemblyRef 5 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformUpper Bracket Jawa 42 Dual DiscRev 36 · PDF p. 191 | Handle Bar Assembly (Jawa - Forty Two)Ref 5.2 · Assembly qty. 1 | Confirm exact bike variant. |
