Upper Bracket B1 Gloss Black
T0505DB10010E
Enquiry ↗CATALOGUE DRAWING
This part is reference 1
BSA Gold Star 650 · Rev 06 · p. 99Original parts list ↗
Highlighted catalogue reference 1. The image shows the complete assembly.
Upper Bracket B1 · T0505DB10010N
Listed in the supplied BSA Gold Star 650 catalogue, revision 06, under Handle Bar Assembly. Match reference 1 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Upper Bracket B1 specifications & catalogue names
- Part number
- T0505DB10010N
- Catalogue part name
- UPPER BRACKET_B1
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| BSA Gold Star 650Upper Bracket B1Rev 06 · PDF p. 112 | Handle Bar AssemblyRef 1 · Assembly qty. 1 | Confirm exact bike variant. |
| BSA Gold Star 650Upper Bracket B1Rev 06 · PDF p. 124 | Headlamp, Tail Lamp, Speedometer & Indicators Front/RearRef 6 · Assembly qty. 1 | Confirm exact bike variant. |
| BSA Scrambler 650Upper Bracket B1Rev 03 · PDF p. 98 | Handle Bar AssemblyRef 4 · Assembly qty. 1 | Confirm exact bike variant. |
| BSA Scrambler 650Upper Bracket B1Rev 03 · PDF p. 110 | Headlamp, Tail Lamp, Speedometer & Indicators Front/RearRef 2 · Assembly qty. 1 | Confirm exact bike variant. |
