Seat Assembly Y4
T09010Y40020N
Enquiry ↗CATALOGUE DRAWING
This part is reference 1.1
Yezdi Scrambler LWE · Rev 04 · p. 71Original parts list ↗
Highlighted catalogue reference 1.1. The image shows the complete assembly.
Seat Assembly-Y4 Brown (Grey Panther) · T09010Y40030N
Listed in the supplied Yezdi Scrambler LWE catalogue, revision 04, under Seat Assembly. Match reference 1.1 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Seat Assembly-Y4 Brown (Grey Panther) specifications & catalogue names
- Part number
- T09010Y40030N
- Catalogue part name
- SEAT ASSEMBLY-Y4 BROWN (GREY PANTHER)
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Yezdi Scrambler LWESeat Assembly-Y4 Brown (Grey Panther)Rev 04 · PDF p. 83 | Seat AssemblyRef 1.1 · Assembly qty. 1 | Confirm exact bike variant. |
