Rear Wheel Mt 4.25X17
T1201AJ10030N
Enquiry ↗CATALOGUE DRAWING
This part is reference 13
Jawa 42 OG All Star · Rev 01 · p. 57Original parts list ↗
Highlighted catalogue reference 13. The image shows the complete assembly.
Axle, Rear Wheel Y5 · T1201GY50010N
Listed in the supplied Jawa 42 OG All Star catalogue, revision 01, under Rear Wheel Assembly. Match reference 13 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Axle, Rear Wheel Y5 specifications & catalogue names
- Part number
- T1201GY50010N
- Catalogue part name
- AXLE, REAR WHEEL_Y5
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 OG All StarAxle, Rear Wheel Y5Rev 01 · PDF p. 69 | Rear Wheel AssemblyRef 13 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi Scrambler LWEAxle, Rear Wheel Y5Rev 04 · PDF p. 79 | Rear Wheel AssemblyRef 18 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi ScramblerAxle, Rear Wheel Y5Rev 19 · PDF p. 92 | Rear Wheel AssemblyRef 18 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi AdventureAxle, Rear Wheel Y5Rev 22 · PDF p. 117 | Rear Wheel Assembly (Tube Tyre Variant)Ref 28 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi AdventureAxle, Rear Wheel Y5Rev 22 · PDF p. 121 | Rear Wheel Assembly (Tubeless Tyre Variant)Ref 26 · Assembly qty. 1 | Confirm exact bike variant. |
