Y5 Frame Assembly Kit Ladder-1
T08000Y50260N
Enquiry ↗CATALOGUE DRAWING
This part is reference 14
Yezdi Adventure · Rev 22 · p. 141Original parts list ↗
Highlighted catalogue reference 14. The image shows the complete assembly.
Frame Cover RH Raven Texture · T13000Y50040T
Listed in the supplied Yezdi Adventure catalogue, revision 22, under Frame Assembly & Frame Mountings-Central Exhaust & Twin Headlamp. Match reference 14 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Frame Cover RH Raven Texture specifications & catalogue names
- Part number
- T13000Y50040T
- Catalogue part name
- FRAME COVER RH_RAVEN TEXTURE
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Yezdi AdventureFrame Cover RH Raven TextureRev 22 · PDF p. 157 | Frame Assembly & Frame Mountings-Central Exhaust & Twin HeadlampRef 14 · Assembly qty. 1 | Confirm exact bike variant. |
