CATALOGUE DRAWING

This part is reference 5

Badge Tank - Perak T13200J30520N — reference 5 in the Jawa Perak Decals - Fwd Footrest assembly drawing
Jawa Perak · Rev 24 · p. 153Original parts list ↗
This part is reference 5
Full-size Decals - Fwd Footrest catalogue drawing
Highlighted catalogue reference 5. The image shows the complete assembly.
Model & variant notes ↓View all parts in this assembly →
PART IDENTIFICATION

Badge Tank - Perak · T13200J30520N

Listed in the supplied Jawa Perak catalogue, revision 24, under Decals - Fwd Footrest. Match reference 5 in the drawing. Assembly quantity: 2. Choose the quantity you need in your enquiry above.

EXACT PART DETAILS

Badge Tank - Perak specifications & catalogue names

Part number
T13200J30520N
Catalogue part name
BADGE TANK - PERAK

Bike catalogues listing this part number

Jawa Perak parts

These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.

CHECK BEFORE ORDERING

Model & catalogue references

Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.

Model / revisionAssembly / referenceSource note
Jawa PerakBadge Tank - PerakRev 24 · PDF p. 166Decals - Fwd FootrestRef 5 · Assembly qty. 2Confirm exact bike variant.

Other parts in this drawing

Open complete drawing →
