CATALOGUE DRAWING

This part is reference 36

RR Unit For Service Kit T14000J30310N — reference 36 in the Jawa Perak Front Fork Mountings assembly drawing
Jawa Perak · Rev 24 · p. 115Original parts list ↗
This part is reference 36
Full-size Front Fork Mountings catalogue drawing
Highlighted catalogue reference 36. The image shows the complete assembly.
Model & variant notes ↓View all parts in this assembly →
PART IDENTIFICATION

RR Unit For Service Kit · T14000J30310N

Listed in the supplied Jawa Perak catalogue, revision 24, under Front Fork Mountings. Match reference 36 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.

EXACT PART DETAILS

RR Unit For Service Kit specifications & catalogue names

Part number
T14000J30310N
Catalogue part name
RR UNIT FOR SERVICE KIT

Bike catalogues listing this part number

Jawa Perak parts

These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.

CHECK BEFORE ORDERING

Model & catalogue references

Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.

Model / revisionAssembly / referenceSource note
Jawa PerakRR Unit For Service KitRev 24 · PDF p. 128Front Fork MountingsRef 36 · Assembly qty. 1Confirm exact bike variant.
