Wiring Battery Positive
T1503AKW0010N
Enquiry ↗CATALOGUE DRAWING
This part is reference 8
Jawa 42 OG All Star · Rev 01 · p. 91Original parts list ↗
Highlighted catalogue reference 8. The image shows the complete assembly.
Ignition Coil With Suppressor Cap · T1502CKW0030N
Listed in the supplied Jawa 42 OG All Star catalogue, revision 01, under Electrical Components And Wiring Harness (1/2). Match reference 8 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Ignition Coil With Suppressor Cap specifications & catalogue names
- Part number
- T1502CKW0030N
- Catalogue part name
- IGNITION COIL WITH SUPPRESSOR CAP
- Also called
- HT coil
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 OG All StarIgnition Coil With Suppressor CapRev 01 · PDF p. 103 | Electrical Components And Wiring Harness (1/2)Ref 8 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIIgnition Coil With Suppressor CapRev 06 · PDF p. 122 | Wiring Harness & Electrical ComponentsRef 4 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIIgnition Coil With Suppressor CapRev 06 · PDF p. 124 | Electronic Fuel Injection (EFI) AssemblyRef 5 · Assembly qty. 1 | Confirm exact bike variant. |
