Tank Recovery - Cooling System
T0401DKW0010N
Enquiry ↗CATALOGUE DRAWING
This part is reference 7
Jawa 42 Bobber · Rev 17 · p. 81Original parts list ↗
Highlighted catalogue reference 7. The image shows the complete assembly.
Bash Plate · T08000KW0300F
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Radiator. Match reference 7 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Bash Plate specifications & catalogue names
- Part number
- T08000KW0300F
- Catalogue part name
- BASH PLATE
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberBash PlateRev 17 · PDF p. 94 | RadiatorRef 7 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakBash PlateRev 24 · PDF p. 102 | RadiatorRef 7 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformBash PlateRev 36 · PDF p. 113 | RadiatorRef 7 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformBash PlateRev 36 · PDF p. 139 | Silencer Assembly - BSIVRef 8 · Assembly qty. 1 | Confirm exact bike variant. |
