Enquiry ↗CATALOGUE DRAWING
This part is reference 15
Jawa 42 Bobber · Rev 17 · p. 115Original parts list ↗
Highlighted catalogue reference 15. The image shows the complete assembly.
Bracket Relay Mounting · T13010J30080N
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Side Panel LH & RH Assy / ECU & Relay / Fusebox / Lock Set Kit. Match reference 15 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Bracket Relay Mounting specifications & catalogue names
- Part number
- T13010J30080N
- Catalogue part name
- BRACKET RELAY MOUNTING
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberBracket Relay MountingRev 17 · PDF p. 128 | Side Panel LH & RH Assy / ECU & Relay / Fusebox / Lock Set KitRef 15 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakBracket Relay MountingRev 24 · PDF p. 132 | Side Panel LH & RH Assy / ECU & Relay / FuseboxRef 15 · Assembly qty. 1 | Confirm exact bike variant. |
