Frame Assembly Kit (Regular Footrest Frame With Expansion Chamber Bracket)
T08000J30150N
Enquiry ↗CATALOGUE DRAWING
This part is reference 1.2
Jawa 42 Bobber · Rev 17 · p. 119Original parts list ↗
Highlighted catalogue reference 1.2. The image shows the complete assembly.
Frame Kit With Ignition Switch Cover (Frame Without Expansion Chamber Bracket) · T14000J30470N
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Frame Assembly & Frame Mountings. Match reference 1.2 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Frame Kit With Ignition Switch Cover (Frame Without Expansion Chamber Bracket) specifications & catalogue names
- Part number
- T14000J30470N
- Catalogue part name
- FRAME KIT WITH IGNITION SWITCH COVER (FRAME WITHOUT EXPANSION CHAMBER BRACKET)
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberFrame Kit With Ignition Switch Cover (Frame Without Expansion Chamber Bracket)Rev 17 · PDF p. 132 | Frame Assembly & Frame MountingsRef 1.2 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakFrame Kit With Ignition Switch Cover (Frame Without Expansion Chamber Bracket)Rev 24 · PDF p. 136 | Frame Assembly / Frame & Mountings / Footrest AssemblyRef 1.2 · Assembly qty. 1 | Confirm exact bike variant. |
