Ignition Switch Assembly
T1501NB10090N
Enquiry ↗CATALOGUE DRAWING
This part is reference 22
BSA Scrambler 650 · Rev 03 · p. 99Original parts list ↗
Highlighted catalogue reference 22. The image shows the complete assembly.
Speedometer Assembly- B401 · T1501HB40030N
Listed in the supplied BSA Scrambler 650 catalogue, revision 03, under Headlamp, Tail Lamp, Speedometer & Indicators Front/Rear. Match reference 22 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Speedometer Assembly- B401 (Domestic)
Speedometer Assembly- B401 specifications & catalogue names
- Part number
- T1501HB40030N
- Catalogue part name
- SPEEDOMETER ASSEMBLY- B401 / SPEEDOMETER ASSEMBLY- B401 (DOMESTIC)
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| BSA Scrambler 650Speedometer Assembly- B401Rev 03 · PDF p. 110 | Headlamp, Tail Lamp, Speedometer & Indicators Front/RearRef 22 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi Scrambler LWESpeedometer Assembly- B401 (Domestic)Rev 04 · PDF p. 113 | Electrical PartsRef 1 · Assembly qty. 1 | Confirm exact bike variant. |
