This part is reference 3
Jawa Perak · Rev 24 · p. 51Original parts list ↗
Highlighted catalogue reference 3. The image shows the complete assembly.
Stator Assembly · T1502AUF0140N
Listed in the supplied Jawa Perak catalogue, revision 24, under Magneto Cover LH - Bs Vi. Match reference 3 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Stator Assembly specifications & catalogue names
- Part number
- T1502AUF0140N
- Catalogue part name
- STATOR ASSEMBLY
- Also called
- Magnet coil
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa PerakStator AssemblyRev 24 · PDF p. 64 | Magneto Cover LH - Bs ViRef 3 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakStator AssemblyRev 24 · PDF p. 66 | Magneto Cover LH - OBD IIRef 3 · Assembly qty. 1 | Confirm exact bike variant. |
