Tube Front Foot Rest RH
T2201AKW0090N
Enquiry ↗CATALOGUE DRAWING
This part is reference 18
Jawa Perak · Rev 24 · p. 75Original parts list ↗
Highlighted catalogue reference 18. The image shows the complete assembly.
Nut Hex M6X1X5X8 · SF0301005
Listed in the supplied Jawa Perak catalogue, revision 24, under Footrest Assembly / Rear Brake Pedal / Gear Shift Lever / Lock. Match reference 18 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Nut Hex M6X1X5X8Xzn
- Nut Hex Fl M6X1X6X8 Gr
Nut Hex M6X1X5X8 specifications & catalogue names
- Part number
- SF0301005
- Catalogue part name
- NUT HEX M6X1X5X8 / NUT HEX M6X1X5X8XZN / NUT HEX FL M6X1X6X8 GR
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa PerakNut Hex M6X1X5X8Rev 24 · PDF p. 88 | Footrest Assembly / Rear Brake Pedal / Gear Shift Lever / LockRef 18 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformNut Hex M6X1X5X8XznRev 36 · PDF p. 97 | Foot Rest Assembly/ Rear Brake Pedal/ Gear Shift Lever / Lock SetRef 25 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformNut Hex Fl M6X1X6X8 GrRev 36 · PDF p. 119 | Rear Brake AssemblyRef 9 · Assembly qty. 1 | Confirm exact bike variant. |
