Sub Frame Assembly J201
T08000J20130N
Enquiry ↗CATALOGUE DRAWING
This part is reference 25
Jawa 350 · Rev 05 · p. 91Original parts list ↗
Highlighted catalogue reference 25. The image shows the complete assembly.
Bracket Bash Plate Mounting · T08000KW0800N
Listed in the supplied Jawa 350 catalogue, revision 05, under Frame Assembly/ Sub Frame Assembly. Match reference 25 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Bash Plate Mounting Bracket Bobber Ug
- Bash Plate Mounting Bracket
- Bash Plate Mounting Bracket Fwd Footrest
- Bracket Bash Plate Mounting Jawa 42 Ug 2.2
- Bracket Bash Plate Mounting Fwd Footrest
Bracket Bash Plate Mounting specifications & catalogue names
- Part number
- T08000KW0800N
- Catalogue part name
- BRACKET BASH PLATE MOUNTING / BASH PLATE MOUNTING BRACKET_BOBBER UG / BASH PLATE MOUNTING BRACKET / BASH PLATE MOUNTING BRACKET_FWD FOOTREST / BRACKET BASH PLATE MOUNTING_JAWA 42 UG 2.2 / BRACKET BASH PLATE MOUNTING_FWD FOOTREST
Bike catalogues listing this part number
Jawa 350 partsJawa 42 Bobber partsJawa 42 FJ partsJawa 42 OG All Star partsJawa Perak partsJawa & Jawa 42 Platform partsYezdi Roadster Mark II partsYezdi Roadster parts
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 350Bracket Bash Plate MountingRev 05 · PDF p. 102 | Frame Assembly/ Sub Frame AssemblyRef 25 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa 42 BobberBash Plate Mounting Bracket Bobber UgRev 17 · PDF p. 96 | RadiatorRef 39 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa 42 FJBash Plate Mounting BracketRev 09 · PDF p. 102 | Frame Assembly / Frame & Mountings / Side Stand / Grab HandlesRef 5 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa 42 OG All StarBash Plate Mounting BracketRev 01 · PDF p. 91 | Frame Assembly & Frame MountingsRef 11 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakBash Plate Mounting Bracket Fwd FootrestRev 24 · PDF p. 104 | RadiatorRef 39 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformBracket Bash Plate Mounting Jawa 42 Ug 2.2Rev 36 · PDF p. 117 | Cooling SystemRef 13 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIBash Plate Mounting BracketRev 06 · PDF p. 106 | Frame Assembly / Frame & Mountings / Side StandRef 10 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi RoadsterBracket Bash Plate Mounting Fwd FootrestRev 22 · PDF p. 104 | Radiator & Cooling System (2/2)Ref 13.1 · Assembly qty. 1 | Confirm exact bike variant. |
