Rider Footrest Assembly LH
T22010J30010T
Enquiry ↗CATALOGUE DRAWING
This part is reference 9
Jawa 42 Bobber · Rev 17 · p. 121Original parts list ↗
Highlighted catalogue reference 9. The image shows the complete assembly.
Socket Head Screw M8X70 · TSF0212016
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Footrest Assembly LH & RH. Match reference 9 in the drawing. Assembly quantity: 1. Choose the quantity you need in your enquiry above.
Socket Head Screw M8X70 specifications & catalogue names
- Part number
- TSF0212016
- Catalogue part name
- SOCKET HEAD SCREW M8X70
Bike catalogues listing this part number
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberSocket Head Screw M8X70Rev 17 · PDF p. 134 | Footrest Assembly LH & RHRef 9 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakSocket Head Screw M8X70Rev 24 · PDF p. 92 | Footrest Assembly LH & RH - Fwd FootrestRef 9 · Assembly qty. 1 | Confirm exact bike variant. |
| Jawa PerakSocket Head Screw M8X70Rev 24 · PDF p. 136 | Frame Assembly / Frame & Mountings / Footrest AssemblyRef 18 · Assembly qty. 1 | Confirm exact bike variant. |
| BSA Scrambler 650Socket Head Screw M8X70Rev 03 · PDF p. 92 | Frame, Sub Frame & Mountings - (1/2)Ref 22 · Assembly qty. 2 | Confirm exact bike variant. |
