This part is reference 29
Jawa 42 Bobber · Rev 17 · p. 123Original parts list ↗
Highlighted catalogue reference 29. The image shows the complete assembly.
Pivot Rider Footrest Bobber Ug · T2201BY50080N
Listed in the supplied Jawa 42 Bobber catalogue, revision 17, under Footrest Assembly LH & RH. Match reference 29 in the drawing. Assembly quantity: 2. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Pivot Rider Footrest
Pivot Rider Footrest Bobber Ug specifications & catalogue names
- Part number
- T2201BY50080N
- Catalogue part name
- PIVOT RIDER FOOTREST_BOBBER UG / PIVOT RIDER FOOTREST
Bike catalogues listing this part number
Jawa 42 Bobber partsJawa 42 FJ partsJawa 42 OG All Star partsJawa Perak partsYezdi Roadster Mark II partsYezdi Roadster partsBSA Scrambler 650 partsYezdi Scrambler partsYezdi Adventure parts
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 42 BobberPivot Rider Footrest Bobber UgRev 17 · PDF p. 136 | Footrest Assembly LH & RHRef 29 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 FJPivot Rider FootrestRev 09 · PDF p. 62 | Footrest Assembly LH & RHRef 4 · Assembly qty. 4 | Confirm exact bike variant. |
| Jawa 42 OG All StarPivot Rider FootrestRev 01 · PDF p. 57 | Footrest Assembly LH & RHRef 4 · Assembly qty. 4 | Confirm exact bike variant. |
| Jawa PerakPivot Rider FootrestRev 24 · PDF p. 92 | Footrest Assembly LH & RH - Fwd FootrestRef 18 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIPivot Rider FootrestRev 06 · PDF p. 64 | Footrest Assembly LH & RHRef 20 · Assembly qty. 4 | Confirm exact bike variant. |
| Yezdi RoadsterPivot Rider FootrestRev 22 · PDF p. 92 | Footrest Assembly LH & RHRef 12 · Assembly qty. 2 | Confirm exact bike variant. |
| BSA Scrambler 650Pivot Rider FootrestRev 03 · PDF p. 58 | Foot Rest Assembly And Rear Brake PedalRef 5 · Assembly qty. 4 | Confirm exact bike variant. |
| Yezdi ScramblerPivot Rider FootrestRev 19 · PDF p. 70 | Rider Footrest Assly LH & RH / Rear Brake PedalRef 7 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi AdventurePivot Rider FootrestRev 22 · PDF p. 81 | Rider Foot Rest Assembly / Rear Brake Pedal / Gear Shift LeverRef 7 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi AdventurePivot Rider FootrestRev 22 · PDF p. 85 | Pillion Foot Rest Assembly LH & RHRef 1 · Assembly qty. 1 | Confirm exact bike variant. |
