Bolt Hex Fl M10X1.25X150X10.9
SF0102545
Enquiry ↗CATALOGUE DRAWING
This part is reference 8
Jawa 350 · Rev 05 · p. 93Original parts list ↗
Highlighted catalogue reference 8. The image shows the complete assembly.
Flanged Bolt M10 X 125 · TSF0102300
Listed in the supplied Jawa 350 catalogue, revision 05, under Engine Mounting System. Match reference 8 in the drawing. Assembly quantity: 2. Choose the quantity you need in your enquiry above.
Other catalogue names for this part number
- Flanged Bolt M10 X 125
Flanged Bolt M10 X 125 specifications & catalogue names
- Part number
- TSF0102300
- Catalogue part name
- FLANGED BOLT M10 X 125 / FLANGED BOLT M10 x 125
Bike catalogues listing this part number
Jawa 350 partsJawa 42 Bobber partsJawa 42 FJ partsJawa 42 OG All Star partsJawa Perak partsJawa & Jawa 42 Platform partsYezdi Roadster Mark II partsYezdi Roadster partsYezdi Scrambler LWE partsYezdi Scrambler partsYezdi Adventure parts
These are catalogue references. Confirm your model year, BS/OBD version and any colour or size notes before ordering.
Model & catalogue references
Match your bike version and these notes. A shared part number does not confirm compatibility with every model year.
| Model / revision | Assembly / reference | Source note |
|---|---|---|
| Jawa 350Flanged Bolt M10 X 125Rev 05 · PDF p. 104 | Engine Mounting SystemRef 8 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 BobberFlanged Bolt M10 X 125Rev 17 · PDF p. 138 | Engine Mounting System & Gear Shift Lever AssemblyRef 5 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 FJFlanged Bolt M10 X 125Rev 09 · PDF p. 108 | Engine Mounting SystemRef 8 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa 42 OG All StarFlanged Bolt M10 X 125Rev 01 · PDF p. 95 | Engine Mounting SystemRef 8 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa PerakFlanged Bolt M10 X 125Rev 24 · PDF p. 140 | Engine Mounting SystemRef 5 · Assembly qty. 2 | Confirm exact bike variant. |
| Jawa & Jawa 42 PlatformFlanged Bolt M10 X 125Rev 36 · PDF p. 179 | Frame Assembly & Frame MountingsRef 18 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi Roadster Mark IIFlanged Bolt M10 X 125Rev 06 · PDF p. 112 | Engine Mounting SystemRef 8 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi RoadsterFlanged Bolt M10 X 125Rev 22 · PDF p. 140 | Engine Mounting SystemRef 9 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi Scrambler LWEFlanged Bolt M10 X 125Rev 04 · PDF p. 101 | Engine Mounting SystemRef 2 · Assembly qty. 1 | Confirm exact bike variant. |
| Yezdi ScramblerFlanged Bolt M10 X 125Rev 19 · PDF p. 116 | Engine Mounting SystemRef 5 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi AdventureFlanged Bolt M10 X 125Rev 22 · PDF p. 159 | Engine Mountings & Side Stand Assembly - Side ExhaustRef 5 · Assembly qty. 2 | Confirm exact bike variant. |
| Yezdi AdventureFlanged Bolt M10 X 125Rev 22 · PDF p. 161 | Engine Mountings & Side Stand Assembly- Central Exhaust & Twin HeadlampRef 4 · Assembly qty. 1 | Confirm exact bike variant. |
